Protégé MRI™ and Prodigy MRI™ IPGs allow 1.5 T head and extremity MRI scans when coupled with the correct lead. All of our lead anchor models can be used.
Prior to scanning a patient, please consult the MR Procedure Information Clinician's Manual.
Protégé MRI™ and Prodigy MRI™ IPGs allow 1.5 T head and extremity MRI scans when coupled with the correct lead. All of our lead anchor models can be used.
Prior to scanning a patient, please consult the MR Procedure Information Clinician's Manual.
WARNING
For an MR Conditional system, all implanted components must be approved MR Conditional models and implanted in approved locations according to the table. If the implanted system contains any other components or models, then the system is considered untested for an MRI environment. In addition, a component must be implanted according to its approved location or the entire implanted system is considered untested.
| MR Conditional | Yes |
|---|---|
| Static Magnet Strength | 1.5T |
| Scanner Type | Cylindrical-bore, horizontal field |
| Scan Region | Head and extremity scans only |
| Max Spatial Gradient | 3000 Gauss/cm |
| Max Slew Rate | 200 T/m/s |
| RF Coil* | Head scans: Detachable head transmit receive coil Extremity scans (all except hip and shoulder): Detachable extremity transmit-receive coil *Circularly polarized only |
| RF Power | Normal Operating Mode |
| System Programming | MRI mode activated; stimulation off |
| Total Active Scan Time | 30 minutes total of active scan time per session 30 minute wait between sessions |
| Additional Restrictions | Refer to IFU for more information |
